垫高块B型(配MT系列)
商品介紹
| 型式/规格 | A | B | C | F | G | M | N&N' |
| BHB100@MT110 | 135 | 100 | 100 | 14H7 | 5 | 2X14 | 95 |
| BHB100@MT160 | 230 | 130 | 100 | 18H7 | 5 | 2X18 | 190 |
| BHB100@MT210 | 230 | 146 | 100 | 18H7 | 5 | 2X18 | 190 |
| BHB100@MT255 | 285 | 200 | 100 | 18H7 | 5 | 2X18 | 205 |
| 型式/规格 | O | P | Q | R | S | T | U | 搭配机型 |
| BHB100@MT110 | - | - | - | 25 | 75 | 30 | 50 | MT-110 |
| MT-135 | ||||||||
| BHB100@MT160 | - | - | - | 25 | 140 | 45 | 50 | MT-160 |
| BHB100@MT210 | - | - | - | 25 | 140 | 45 | 50 | MT-210 |
| BHB100@MT255 | - | - | - | 25 | 160 | 62.5 | 50 | MT-255 |
| MT-280 |
单位mm
